Coil Voltage:
3 V dcV dc
Contact Configuration:
DPDT
Mounting Type:
PCB Mount
Maximum Switching Current DC:
2 A
Maximum Switching Voltage AC:
250V
Maximum Switching Voltage DC:
220V dc
Series:
P2
Maximum Switching Power DC:
60 W
Latching:
No
Length:
14.5mm
Depth:
7.4mm
Height:
10.4mm
Dimensions:
14.5 x 10.4 x 7.2mm
Terminal Type:
Surface Mount
Number of Poles:
2
Switching Current:
2A
Application:
Communications Equipment, Consumer Electronics, HiFi, Line Card Applications, Measurement & Control Equipment, Medical Equipment, Office & Business Equipment, PABX, Set Top Boxes, Voice Over IP
Isolation Coil To Contact:
2kV rms
Coil Power:
150mW
Coil Resistance:
64Ω
Life:
100000000 (Mechanical) Operations, 50000000 (Electrical) Operations
Maximum Switching Power AC:
62.5VA
Operating Temperature Range:
-40 → +85°C
Features:
Bifurcated Contacts, Immersion cleanable
Contact Material:
Gold Plated
Minimum Operating Temperature:
-40°C
Relay Switching Classification:
Non-Latching Relay
Standards Met:
cULus
Maximum Operating Temperature:
+85°C
